Impact Test ISO

Standards

ISO 10545-5

Laboratories

Ceramic Tiles Lab

Instrument for the determination of the resistance to the impact of the ceramic tiles. Determination of the coefficient of restitution bydropping a steel ball from a fixed height onto the test specimen and measuring the height of rebound.

TECHNICAL SPECIFICATIONS
• Steel structure epoxi powder painted
• Chrome steel ball Ø 19 ± 0,05 mm
• Microphone to maesuring the rebound
• Thermal printer
• Supply: 240 V – 50/60 Hz single phase

EQUIPMENT
• N° 5 blocks for instrument calibration
• N° 1 block of concrete
• Chrome steel ball Ø 19 ± 0,05 mm
• Magnetic level
• Schuko power cable

Code	Model	External dimensions	Power	Weight
GT0806	IMPACT TEST ISO	500x550x1600 mm	55 W	50 kg

Code	Description	Image
GT0807	N° 5 blocks for instrument calibration with tile	Open image
GT1168	Packing of 20 thermal paper rolls for data processor (CM 400)	Open image
GT1715	N°5 concrete blocks	Open image
GT1522	Chrome steel ball Ø 19 ± 0,05 mm	Open image
GT1648	Magnetic level	Open image

| Data Sheet

| Add to quote
